KT-4H110 4 Post/ four Post Vehicle Lift 11,000lbs
KT-4H110 4 Post/ four Post Vehicle Lift 11,000lbs
Couldn't load pickup availability
KT-4H110 4 Post/ four Post Vehicle Lift 11,000lbs
*Concrete thickness must be at least 3.93” (100 MM) with a 3000 PSI rating. Failure to install this lift on the proper concrete could result in serious injury or death! It is the customer’s responsibility to verify concrete thickness and strength before purchase and installation.
- 11000lbs lifting capacity.
- CE Approved and Certified. It has adopted the 115% dynamic loading capacity standard and was 150% static loading capacity tested.
- Single Point Manual Safety Lock Release
- Four mechanical locking devices, a secondary lock system acts as a slack-cable device to engage in the unlikely event of cable failure.
- Power side column can be installed at both sides, front or rear.
- Non-skid coated platforms and adjustable safety lock ladders.
- Optional caster kit for moving the lift around, and optional rolling jacks.
- *Rolling jacks and casters can be purchased separately but are not included. *
- Comes with two drip trays and a jack tray.
- High-quality hydraulic system with 110V/60HZ/1PH or 220V/60HZ/1PH (Optional)
- Customer must have forklift for unloading.
| Lifting Capacity | 11000 lbs. (4990KG ) |
| Max. Lifting Height | 84.25" / 2140mm |
| Lifting Time | 83s Up / 40s Down |
| Height of Posts | 94.88" / 2410mm |
| Width Overall | 126" / 3200mm |
| Length Overall |
229.73" / 5835mm (with Ramps) |
| Inside Columns | 112.81" / 2865mm |
| Min. Runway Height |
6.2" / 157mm |
| Motor | 110VAC/60HZ/1PH |
| Net Weight | 2116lbs / 960KG |
|
Please feel free to contact us before purchasing. Please let us know which warehouse would be the preferred pickup location. We can help to check the availability. 12 Months All Parts Warranty! |
